SL-9560 One-component Thermal Conductive Adhesive 6.0 W/m·K

Product Introduction：

SL-9560 is a one-component non-curable organic silicone thermal conductive gel product with a thermal conductivity of 6.0W-mk.

This product possesses excellent characteristics such as high thermal conductivity, high extrusion rate, and low volatility. It has good wetting properties on the substrate and is suitable for filling the gaps between various power dissipation devices and heat dissipation interfaces.

Brand：DFN

Model：SL-9560

Shelf life: 6 months

Enquiry Hotline：+86-0755-85228809

Product Specification

Product Name

Single-component thermal conductive gel

Manufacturer

DFN

Temperature range

-60°C to +200°C

Viscosity (Pa.s)

600~900

Extrusion rate g (90 psi/min)

20~40

Shelf life

Store in a dry place for 6 months

Product model

SL-9560

Product color

Light blue

Product Specifications

30ML/50ML/330ML/600ML

Specific gravity

3.3g/cm³

Dielectric strength

>6KV/mm

Thermal conductivity

6.0W/m·K

Application field

5G communication base station equipment

DC-DC control system

Mobile phone chip

Matters needing attention

1. Before applying the glue, it is necessary to ensure that the application area is clean and dry.

2. If the product is not used up at one time, it should be sealed and stored separately.

3. The product should be stored in a sealed container in a cool and dry place. The shelf life is 6 months.

4. If this product accidentally comes into contact with your skin, please immediately wash it off with soapy water. If it accidentally gets into your eyes, first rinse them with plenty of water, and then seek medical attention.

5. When using this product, any unused chemicals should not be discarded at will, as doing so may lead to accidents.

6. Please store it away from children. When using this product, use necessary protective equipment such as respirators, rubber gloves, and safety clothing to prevent any unknown adverse effects.
